Maipu PU3320-4G XGSPON Industrial HGU
PU3320-4G ONU is an industrial-grade 10-Gigabit ONU developed and produced by Maipu. The product complies with IEEE 802.3av(10G EPON) and ITU-T G.987.x (XGSPON) standards, has good interoperability and operability.
PU3320-4G adopts mature technology and open network standards development, quasi-industrial design, adapt to complex high and low temperature difference environment, strong anti-electromagnetic interference, to meet different working environment requirements. For the industrial Internet of things to provide efficient, reliable, fast solutions, equipment security, stability and reliability, suitable for continuous operation of the industrial communication
PU3320-4G provides 1*XGSPON Port,1*2.5GE Port and 3*GE Ports.
(Note: The product information may not be latest. For the latest, please contact overseas@maipu.com）
Product Features
. 10 Gigabit Access Adaptive 10G EPON and XGSPON OLT
. Wide Temperature Design, Stable Working Environment Temperature -40℃~70℃
. Port 4KV, Power Supply 6KV Lightning Protection
Product Specifications
|
Hardware Specification |
||
|
PON interface |
RX sensitivity: -29dBm |
|
|
Transmission distance: 20km |
||
|
Wavelength |
XGSPON: DS 1577nm/US 1270nm |
|
|
Symmetrical 10G-EPON: DS 1310nm/US 1577nm |
||
|
Optical interface |
SC single mode, SC/UPC connector, Class B+ |
|
|
LAN interface |
1*2.5GE, Auto-negotiation, RJ45 ports |
|
|
3*GE, Auto-negotiation, RJ45 ports |
||
|
Transmission Rate |
XGSPON: Up 6Gbps; Down 10Gbps |
|
|
10G EPON: upstream 6Gbps; Down 10Gbps |
||
|
XGPON: Uplink 2.5Gbps; Down 10Gbps |
||
|
Operating Environment |
Temperature: -40℃～+70℃ |
|
|
Humidity: 5%～90%（non-condensing） |
||
|
Storing Environment |
Temperature: -40℃～+85℃ |
|
|
Humidity: 5%～95%（non-condensing） |
||
|
Power Supply |
DC 12V/1A |
|
|
Power Consumption |
Full Load ≤18W；Ldle ≤4W |
|
|
Dimension |
125mm×120mm×31m(L×W×H) |
|
|
Weight |
0.61Kg |
|
|
Installation Mode |
Wall-mountable, Desktop |
|
|
Software Key Feature |
||
|
Layer 2 Features |
MAC Addresses |
Supports up to 1K MAC addresses. |
|
VLAN |
- Port-based VLAN (IEEE 802.1Q) |
|
|
- VLAN conversion supported |
||
|
- Supports up to 4096 VLAN entries |
||
|
- Supports port isolation within the same VLAN |
||
|
Ports |
- Bandwidth control supported |
|
|
- Supports port flow control |
||
|
- Port mirroring supported |
||
|
Security Features |
User Security |
- Supports MAC address authentication, binding to ports, and MAC address filtering. |
|
Device Security |
- Control layer protection against various DOS and CPU-targeted virus attacks. |
|
|
Network Security |
- Supports suppression of broadcast/multicast storms and provides security isolation between interfaces. |
|
|
QoS |
Flow Control |
- Backpressure flow control (half-duplex), IEEE 802.3x flow control (full-duplex). |
|
Port Rate Limiting and Traffic Classification |
- Supports advanced queue scheduling algorithms, including FIFO, SP, and WRR, based on ports, IEEE 802.1P, and CoS, as well as custom TCP/UDP ports. |
|
|
Multicast |
IGMP Snooping |
- Supports IGMPv1/v2/v3 snooping. |
|
- Cross-VLAN multicast support. |
||
|
Equipment Protection |
Lightning Protection |
- All ports support signal lightning protection of over 6kV. |
|
Power Surge Protection |
- Power supply supports surge protection above 4kV. |
|
|
Software Features |
HGU |
- Supports up to 8 WAN interfaces for routing. |
|
- Bridge modes supported: tagging, transparent transmission, trunking, translation. |
||
|
SFU |
- Optional isolation, exchange, tagging, transparent transmission, trunking, and translation supported. |
|
|
Maintenance & Management |
Network Maintenance |
- Web-based statistics on port inbound/outbound traffic. |
|
Equipment Management |
- Web-based configuration management and Telnet CLI supported. |
|
|
- Configuration file import/export for batch configurations. |
||
|
Firewall |
Security |
- Supports IP address and port filtering. |
|
Other Features |
Logging |
- System logging supported. |
